Streetjam OTA-R3R

Postby joseph-Ontherun » Sat Jan 14, 2012 5:08 pm

Make:streetjam
Model:ota-R3R

Track surface: carpet
Tire: rc art 5004/stj Dt 0010(Pc)
Motor & ESC: Lrp sxx tc spec + dualsky 7.5t

Front

Camber: 3
Toe: 1
Kick up: 3mm
Caster hubs: 7deg
Ride height: 5.5
Springs: medium (stj soft series)
Bumper weight: -
Trailing Steering Block: -
Sway-Bar: -
Shock Oil: 550#
Other:

Rear

Camber: 0
Toe: -3 (stock)
Kick up: -
Ride height: 6.5
Springs: soft (stj soft series)
Sway-Bar: -
Shock Oil: 250#
Other:

Drive Train

Gearing: 39/13 19/16 17/39

Spur:121
Pinion:22
Other:
- custom front belt (174mm)
- custom center belt


User avatar
Murdock
Still Turns In
Still Turns In
Posts: 254
Joined: Sat Nov 27, 2010 5:14 am
Drift Chassis: VDF, DRB, TCX, E4FS, R31
Location: Norcal, California

Re: Streetjam OTA-R3R

Postby Murdock » Sat Jan 14, 2012 11:15 pm

:up:
MST - MS-01D Pro - Build thread click HERE
Tamiya - TA05VDF - Build thread click HERE
HB/HPI - TC-FD - Build thread click HERE
Yokomo - SSG DRB - Build thread click HERE

Khalikul
What's CS?
What's CS?
Posts: 5
Joined: Thu May 31, 2012 11:39 pm
Drift Chassis: R31 cs 1.66
Location: Malaysia

Re: Streetjam OTA-R3R

Postby Khalikul » Sun Jul 15, 2012 10:16 am

Nice. But can i know what is yr rim off set?
